发布日期：2017-09-04 15:05:36 浏览次数：2338
| 型号 | 流量 | 扬程 | 转速 | 功率KW | 效率 | 气蚀余量 | |
| WRY | m3/h | m | r/min | 轴功率 | 配用功率 | η% | NPSH |
| 150-125-260 | 150 | 16 | 1460 | 8.5 | 11 | 76 | 2.5 |
| 150-125-320 | 120 | 30 | 1460 | 12 | 11 | 74 | 3 |
| 150-125-270 | 160 | 18 | 1460 | 12 | 15 | 74 | 3 |
| 150-125-360 | 120 | 36 | 1460 | 11.76 | 15 | 74 | 4 |
| 150-125-380 | 130 | 40 | 1460 | 15 | 18.5 | 78 | 3.8 |
| 150-125-280 | 180 | 20 | 1460 | 15 | 18.5 | 78 | 3.8 |
| 150-125-320A | 200 | 32 | 1470 | 26 | 30 | 70 | 3.6 |
| 150-125-350 | 140 | 38 | 1470 | 20 | 22 | 70 | 3.6 |
| 150-125-380A | 160 | 48 | 1470 | 25 | 30 | 72 | 3.6 |
| 150-125-400 | 180 | 50 | 1475 | 31 | 37 | 75 | 4 |
| 200-150-400 | 260 | 50 | 1480 | 35 | 45 | 76 | 4.5 |
| 200-150-430 | 240 | 60 | 1480 | 39 | 45 | 78 | 5 |
| 200-150-410 | 300 | 50 | 1480 | 44 | 55 | 80 | 5 |
| 200-150-430A | 280 | 60 | 1480 | 47 | 55 | 78 | 5.5 |
| 200-150-420 | 400 | 50 | 1480 | 61 | 75 | 82 | 6 |
| 200-150-440 | 380 | 60 | 1480 | 64 | 75 | 80 | 6.5 |
| 200-150-470 | 300 | 70 | 1480 | 63 | 75 | 78.2 | 6 |
| 200-150-390 | 450 | 50 | 1480 | 75 | 90 | 82 | 6.5 |
| 200-150-450 | 420 | 60 | 1480 | 80 | 90 | 80 | 7 |
| 200-150-475 | 350 | 70 | 1480 | 81 | 90 | 82 | 7 |
| 250-200-425 | 430 | 70 | 1480 | 92 | 110 | 84 | 8 |
| 250-200-460 | 460 | 60 | 1480 | 94 | 110 | 82 | 8 |
| 250-200-470 | 560 | 60 | 1480 | 115 | 132 | 84 | 8.5 |
| 250-200-480 | 500 | 70 | 1480 | 110 | 132 | 84 | 8.5 |
